     DK-MC50 multichannel process analyser

    Characteristics

    High precision, UI friendly online analyser

    Full-color display

    Up to four sensor inputs

    Up to eight current outputs

    Up to six channel alarm and controller relay output

    Seven optional languages



     DK-MC50 多通道过程分析仪1.png

    Overview

    The dk-mc50 multi-channel process analyzer can measure dissolved ozone, pH/ORP, conductivity, dissolved oxygen, residual chlorine, turbidity and suspended particulate matter.





    Specification

    Range : 0 - 10 ppm (0 - 10000 ppb)

    Accuracy :   +/- 1%

    Resolution:  0.01 ppm (10 ppb)

    Limited detection : 0.1 ppm (100 ppb)DK-MC50 多通道过程分析仪3.png

    Display unit: ppm

    Response time: 1s

    Measurement principle:  polarography

    Display : digital

    Built-in memory:  contained

    Analog output:   8 channel

    Communication protocol: none

    Temperature range: -4 ~140°F (-20~ 60°C)

    Power supply: 120 - 240 VAC 60 Hz

    Dimension:  6.8 x 3.8 x 5.7 inches (17.3 x 9.7 x 14.5 cm)

    Weight : 3 lbs (1.36 kg)

    Quality assurance period    1 year

    Relay                     3
