    Gasera One trace level photoacoustic spectroscopy multi-gas analyzer

    Overview

    Trace impurity gases such as hydrocarbons, H2O, CO, CO2, NOx, N2, H2S, etc., are harmful to the production of high purity helium, high purity hydrogen, high purity nitrogen, other high purity gases and olefin gases. It can damage production equipment and affect production quality, and even pose a fatal threat to equipment that USES these gases. The DKF10-MH trace level multi-component gas analyzer developed by Duketech and Finland Gasera co., ltd. specializes in the monitoring and analysis of PPM micro-level and PPB ultra-micro level impurity gases.





    Principle

    DKF10-MH trace level multi-component gas analyzer based on infrared photoacoustic technology. It has a pulse infrared light source, through narrow band optical filter, forming 10 spectral bands in the middle infrared region, for gas analysis. Ultra-high sensitivity based on patented  enhanced cantilever optical microphone technology. which can be achieved through 10 optical narrowband filters. Extremely narrow optical filters can remove the interference of background gas. Multiple spectral regions can facilitate minimum cross sensitivity. The sampling response results were calibrated according to the improved classical least square method. Photoacoustic spectroscopy technology can realize high sensitivity measurement of short optical path, further improve the nonlinear compensation technology, can achieve wide range up to 5 levels of linear dynamic range ratio



    Gases

    Hydrocarbons : CH4 C2H6 C2H2 C2H4 etc.

    Inorganic gases: CO2、CO、N2O、SO2、NO、NO2, NH3、NF3、SF6、H2O etc.

    Volatile organic compounds (VOCs): Acetone, ethanol, methanol, benzene, toluene, xylene, formaldehyde etc.

    Freon(CFCs) and perfluorocarbon(PFCs):  CF4、 C2F6、R-134a、R13 etc.

    Corrosive gas: HF、HCL、HCN etc.

    Anesthetic: Isoflurane, sevoflurane, desflurane, anflurane

    Other gases: N2、H2、O2、Cl2 etc. (optional    extended probe)

    Customizable measuring gases



    Application

    Up to 9 gases  measured simultaneously

    PPB, sub-ppm level limited detection

    Instant measurement, real-time analysis, second response time

    Long calibration period, low sample volume

    High - resolution graphic display interface, friendly UI

    Rich programmable measurement tasks

    Graphs and tables show all gas measurements

    Built-in trending view monitoring tasks

    No external computer is required

    No consumables, maintenance free

    4-20mA analog RS232 RS 485 communication

    Rugged case design





    Advantages

    Infrared photoacoustic spectroscopy with an optical microphone with an enhanced cantilever

    Electronic pulse infrared light source

    Gold-plated sampling chamber constant temperature 50 ° C

    Patented ultra-sensitive optical microphone based on MEMS cantilever sensor, coupling laser interferometry to measure the micro movement of the cantilever beam

    19"3U industrial chassis, suitable for all bench or rack mounting

    Embedded computer with a 5.7" front-facing display settable gas alarm threshold

    The data storage is about 2GB, sufficient 9 kinds of gas stored continuously for one year

    Measurement results exportable via USB drives, USB ports, Ethernet network ports, and serial ports

    Four gas connects in rear panel, two for sampling with dust particle filters

    Automatic compensation for temperature, pressure and other changes in the operation condition of interference



    Specification

    Response time: According to the channel integral time (C.I.T.) and gas exchange cycle, typically it takes 30s to a few minutes.

    Limited detection: sub-ppm, customizable

    Repeatability: 1% of measurement result (under calibration condition)

    Accuracy: typical 2~5%

    Dynamic range: typical 5 orders  100,000 detection limits

    Zero drift: 1% detection limit/year

    Span drift: 3% measurement value/year

    Operation condition:

     temperature range: 0 °C – +45 °C

    Humidity range: lower than 90% RH   no condensation

    Pressure range: atmosphere

    Protection grade:  IP20 (IEC 529)





    Vibration test: 33 Hz strong vibration

    Storage condition: temperature range: -20 °C – +60 °C

    Sampling condition:  temperature range: 0 – +49 °C  no condensation

    Pressure range: 930 mbar – 1100 mbar

    Humidity range:  dew point: +8 °C or higher

    Flow rate: approximately 1L/min

    Particle : < 1 μm

    Dimension: 48.4cm Wx13.9cm Hx40.5cm D (19.1in Wx5.5in Hx16.0in D)

    Weight : approximately 13kg

    Total sampling volume:<30mL optional pump (Negative pressure 100hPa)  longest distance  100 meters

    Gas connection: 6/4mm tube with quick plug, customizable

    Electrical connection

    Power supply: 100 - 240VAC, 50 - 60 Hz

    Input power: 100W

    Communication interface: Ethernet、USB、RS232、RS485
